C&D waste recycling: step by step
Construction waste and excavated soil materials have great potential for recycling. The quality of the recyclates plays a major role here. Binder+Co supplies solutions for every process step:
2. Screening
The second step is to separate the construction waste material according to grain size. Our BIVITEC flip-flow screens are
suitable for this application, as they use flexible screen mats to classify even difficult-to-screen materials reliably and without clogging. For coarser fractions, circular vibrating screens are used to ensure efficient pre-separation. Dewatering screens separate water from solids and can also be used as washing screens to optimally prepare the raw material for optical sorting.
3. Removal of impurities
The removal of impurities at the start of the treatment process is also of great importance. Steel and reinforcing steel are removed with overbelt magnets, non-ferrous metals with eddy current separators. Light organics, plastics and light materials are removed via the BREEZER using an air stream.
4. Wet processing
In wet processing, sticky components such as loam, friable material and clay are dissolved and dust and fines are removed - the ideal preparation for sensor-based sorting. Grains up to 300 mm in size are cleaned in the COMEC-Binder washing drum. Log washers ensure even more intensive cleaning.
Light materials and organic components are removed by a jigging machine .
5. Sensorbased Sorting
Our Clarity sorting machines offer comprehensive solutions for sorting construction waste, excavated soil and dismantled railroad gravel
into pure products. At the heart of the sorting process is material detection, supported by various sensor technologies in different wavelength ranges, such as visible light (VIS), near-infrared (NIR), inductive metal detectors and artificial intelligence.
6. Sand processing
The sand preparation machines from Binder+Co enable the production of standard-compliant sand. Customized sand products can be produced with the compact hydrocyclone systems from COMEC-Binder. With the SANDEXX sand trap and the screw classifier, Binder+Co also offers maintenance-friendly and energy-efficient solutions for grit processing.
7. Process water treatment and sludge dewatering
Our water treatment systems reliably recycle all process water and save up to 85 % of the fresh water required for a sand and gravel washing plant. The separated sludge (< 63 μm) is dewatered using a chamber filter or belt filter press. The filtrate water recovered in the process is fed back into the washing process via the process water treatment system.
Recycling building materials: typical products
Quality instead of downcycling: Our innovative processing technologies enable us to achieve particularly high product qualities. Whether natural stone, old concrete recycling, brick recycling or the processing of other building materials - typical products from construction material recycling are:
- Mineral construction waste: Natural stone, concrete-aggregates, asphalt, bricks, glass, gypsum
- Organic materials: wood, plastics and other organic materials
- Metals: structural steel, copper, aluminum
Yes - on request, we are happy to carry out tests with your material to demonstrate the sortability and efficiency of our technologies under real conditions. Please contact us!
Our service team provides rapid support and is on duty 24/7. Thanks to a high level of vertical integration at our site in Gleisdorf and a constantly available stock, we are independent of external supply chains when it comes to spare parts.
