DRYON fluidized bed dryers and coolers

The DRYON from Binder+Co combines drying and cooling in a single unit.

With Binder+Co, you benefit from innovative solutions for your application:

  • Reduced energy consumption thanks to integrated heat recovery
  • Wide range of applications and flexibility
  • Short dwell times
  • Consistent product quality
  • Gentle drying

CONTACT US

Reduktion der C02-Emissionen durch Abwärmenutzung   Stage Talk zur Fließbetttrocknung

Benefits of the DRYON fluid bed dryer and fluid bed cooler

RELIABLE AND EFFICIENT

The combination of fluidized bed drying and cooling in a single unit enables an efficient process. The waste heat from the cooling zone can be reused in the system. These systems are also characterized by high availability.

HIGH PRODUCT QUALITY

The DRYON delivers consistent product quality through gentle drying and cooling. Our fluid bed dryers and coolers are tailored precisely to your requirements and are available with drying areas ranging from 0.3 m² to 60 m².

ROBUST CONSTRUCTION AND LONG SERVICE LIFE

Our machines impress with their stable construction and minimal wear, ensuring decades of use. Many systems have been in operation for over 30 years.

WIDE RANGE OF MATERIALS

The DRYON processes a wide variety of materials: from coarse to fine, from raw materials to recycled materials. It can be used for industrial minerals, salts, glass, animal feed, and much more.

REDUCED HEAT REQUIREMENTS

The system uses the heat emitted during cooling for thermal drying: a cycle that reduces thermal power requirements while ensuring stable operation.

LOW MAINTENANCE COSTS

We train your staff in operation and maintenance. We produce the spare parts for the DRYON fluidized bed dryer ourselves at our site in Gleisdorf.

How does our fluidized bed dryer work?

Our drying plant is based on an innovative system that guarantees efficient and gentle treatment of a wide variety of materials.

Material feeding: The material is fed onto a perforated conveyor floor. Hot air flows through the perforations during drying, or cool air during cooling. The material moves transversely to the air flow, and the process thus operates according to the cross-flow principle.

Material loosening: The bulk material is loosened either purely by the air flow in static dryers or with the aid of additional vibration. This flexibility allows optimal adaptation to different materials.

Static fluidized bed dryers

A static fluidized bed dryer or fluidized bed cooler works exclusively with air loosening; heat exchangers can be integrated here:

  • Can be used for fine grain sizes up to 6 mm
  • High throughput on a minimal footprint
  • Integration of heat exchangers
  • Significantly reduces the amount of air required
  • Reduces the size of the unit
  • Larger layer heights enable smaller footprints

Vibrating fluidized bed dryers

The vibration enables optimal drying even at low flow rates:

  • Ideal for coarse grains and drying bulk materials with a wide grain spectrum
  • Three different vibration systems depending on requirements
  • Variable residence time control through vibration adjustment
  • Easy product changeover thanks to good emptying properties

What tasks does our DRYON drying plant cover?

As a manufacturer of fluidized bed dryers, we ensure that the DRYON fluidized bed dryer can be used for a wide range of applications:

  • Drying: Drying of bulk materials, primary and recycled raw materials
  • Cooling: Controlled temperature reduction for primary and recycled raw materials
  • Crystallization: Specialized process technology for PET plastics to improve the crystal structure
  • Conditioning: Targeted material processing as a special application in the primary raw materials sector
  • Heating: Precise temperature increase as a process stage mostly required in the potash industry
  • Material dedusting: Effective removal of dust particles from primary and recycled raw materials
  • Organic removal: Removal of organic contaminants, which is usually required for recycled raw materials

FLUIDIZED BED DRYERS FROM BINDER+CO. INDIVIDUAL COMPLETE SOLUTIONS


With over 40 years of expertise, we plan the entire drying process for your specific application. Each fluidized bed dryer and fluidized bed cooler is individually customized: We supply complete drying systems with fans, burners, heat exchangers, electric heating coils, filters, and scrubbers. We also offer various types of bases, such as perforated plate, cascade, or welded slotted screen bases, ensuring the perfect solution for your specific requirements.

HAVE YOUR MATERIAL TESTED

DRYON fluid bed dryer: Principle and mode of operation in detail

Materials and areas of application for fluidized bed dryers

Industrial minerals

DRYON offers a reliable drying solution for industrial minerals such as marble, granite, limestone, quartz, bentonite, clay, magnesite, gypsum, and many other materials.

PROCESSING INDUSTRIAL MINERALS

Construction waste and raw materials

Construction waste must undergo a processing process to make it reusable, and drying is often an essential part of this process. Raw materials often need to be dried after extraction to enable further processing for the construction industry.

CONSTRUCTION WASTE RECYCLING

Potash

DRYON has proven itself in the drying and heating of potash. Static fluidized bed dryers are generally used for this purpose. The use of vibrating fluidized bed dryers is state of the art for the processing of potash granules.

PROCESSING OF POTASH

Glass and waste glass

During the waste glass recycling process, the glass fragments must be dried to make them easier to sort and to remove unwanted organic substances.

GLASS RECYCLING

Rock salt and sea salt

The DRYON is used in the drying of salt (rock salt and sea salt) and in the thermal drying of ammonium sulfate for fertilizers.

Sea salt processing

Sand, gravel, and crushed stone

The drying of sand, gravel, and crushed stone is important to ensure optimum quality for further processing.

SAND PROCESSING

Food and animal feed

To make foodstuffs such as tea, coffee, and pet and livestock feed suitable for packaging and storage, they are dried and cooled using DRYON.

Biomass

Biomass drying is used for various applications, from energy production to use in animal husbandry and the fertilizer industry.

Biomass processing

Chemical products

The vibration of the DRYON ensures consistent product quality in the chemical industry. The fluidized bed system delivers the desired results even with temperature-sensitive goods.

Coal

Our fluidized bed dryer has been used successfully in the coal industry for decades.

To coal processing

Plastics

The DRYON is also used for drying PE/PET flakes, PE/PET granules, and other plastics. The vibrating fluidized bed ensures gentle handling.

Why is fluidized bed drying so important?

Fluidized bed drying plays a crucial role in many industries, as it creates the conditions necessary for subsequent production steps:

+ Preparation for subsequent process stages: The drying process ensures that the material can be further processed. This guarantees the screenability and separation of fine material by sorting machines.

+ Reduced transport costs and improved storability: The increased surface stability of the material optimizes storability. The material can be handled more efficiently and transported more cost-effectively.

+ Consistent product quality: Fluidized bed drying ensures consistent product quality. Thermal drying is often a critical step in achieving the desired properties for a saleable or marketable product.

Reduction of CO₂ footprint

Our technology aims to reduce CO₂ emissions during the drying process to a minimum. By utilizing internal waste heat streams and integrating external energy sources (photovoltaic systems, furnace exhaust gases), we offer an environmentally friendly and efficient solution.

DRYON fluid bed dryers: Brochures available for download


Our brochures provide an overview of the technologies we use in our fluid bed dryers and fluid bed coolers. You can also learn more about the diverse range of applications and industries in which our solutions are used.

Binder+Co LEADING PRODUCTS

Binder+Co DRYON

Frequently asked questions about our fluidized bed dryers

Compared to drum drying, fluidized bed drying requires less heat. The cross-flow principle ensures faster drying with lower thermal energy requirements.

In a belt dryer, the material is transported on a moving belt while warm air flows through the material from above or from the side. In a fluidized bed dryer, on the other hand, the material is loosened, fluidized, and then surrounded by hot air. This technology offers ideal heat transfer and faster and more uniform drying than a belt dryer.

Although fluidized bed dryers are efficient and versatile, there are some limitations:

  • Moisture: The material must be free of free liquid. Free liquid must be removed in advance by mechanical dewatering. However, this is recommended anyway from an operating cost perspective.
  • Material sizes: Fluidized bed dryers are limited to materials with a particle size of 0 to 70 mm, depending on the specific material.

Yes, fluidized bed drying is also used successfully in agriculture, for example in alfalfa drying. Here, the benefits of efficient and uniform drying, which ensures high-quality products, are clear.

Grain drying requires longer residence times, which are difficult to achieve in fluidized bed drying. In this case, shaft dryers or other systems that are specially optimized for such requirements are used.

The fluidized bed dryer is available in various sizes. For smaller applications, there are models with a width of 200 mm and a length of 1500 mm. However, larger machines can also be up to 3 x 20 meters in size, depending on the feed rate and material size.

  • Static fluidized bed dryers: Smaller footprint thanks to greater layer heights.
  • Two-mass oscillation system: Sizes up to 60 m². This machine type is particularly suitable for higher feed rates.
  • Single-mass oscillation system: Sizes up to 16 m².

Drying systems are usually controlled according to the exhaust air temperature. This method offers the advantage of being virtually maintenance-free and very precise at the same time. If necessary, the moisture content of the output material can also be measured in order to control the drying process even more precisely. However, this additional control option is only used in individual cases where even more precise control is required.

Our drying systems are characterized by exceptional durability. Numerous dryer systems have been in successful use for more than 30 years. After decades of service, many systems are simply converted or expanded instead of being completely replaced. The robust design ensures reliable and economical use for decades.
